Anadol Next 13/32 Multiswitch with Wind‑Up Aid,

Here’s a detailed look at the Anadol Next 13/32 Multiswitch with Wind‑Up Aid, ideal for distributing 3 satellite feeds to up to 32 receivers:

📌 Key Specs & Features

• Inputs: Accepts 3 satellites (3 × 4 polarities = 12 SAT + 1 terrestrial) — works only with a Quattro LNB

• Outputs: Delivers independent SAT/TV to 32 subscribers/receivers, each getting all program options

• Frequency Range: Satellite IF 950–2150 MHz; terrestrial 47–862 MHz, suitable for DVB‑T/T2/FM/DAB

• Isolation & Decoupling: High performance—SAT‑SAT and SAT‑TV isolation >25–30 dB, ensuring minimal cross‑signal interference

• Power:

  • External PSU included (usually ~16 V DC / 2 A); powers both switch and LNB outputs (up to ~1600 mA total)

  • Low consumption (~35 W)

• Build & Aids:

  • Gold‑plated F‑connectors for reliable signal.

  • Robust metal casing with mounting feet.

  • Includes wind‑up aid/tool for easier installation

• Compatibility: Supports HD, UHD/4K, 8K, 3D; DiSEqC 2.0/1.0

✅ Benefits & Usage Scenarios

• Perfect for large deployments: Ideal when you want to serve up to 32 TVs or receivers with independent access.

• All-in-one ease: Combines satellite and terrestrial distribution—no external TV/FM amplifier needed.

• Commercial-grade reliability: High decoupling ensures strong signal even with many taps.

• Installer-friendly: Wind‑up aid simplifies cable handling, saving time and reducing fatigue.

⚠️ What to Know Before You Buy

• Requires a Quattro LNB, not a Quad. Ensure your dish is equipped accordingly.

• Needs reliable mains power provisioning—consider a UPS if outages are common

• Designed for indoor protected locations (attic or cabinet) — keep away from rain exposure.

🔧 Setup Considerations

1. Quattro LNB: Must have four separate outputs (V‑Low/High, H‑Low/High).

2. Power Supply: Use the included external PSU (likely 16 V / 2 A).

3. Terr Input: If you want terrestrial TV radio, connect antenna to “Terr” port.

4. Receiver Support: Receivers must support DiSEqC control to switch satellites.

5. Cabling: Use quality coax and secure F‑connector terminations to maintain signal integrity.
