NHE Multiswitch MS1316-C

🛠️ Model Summary

• Model: NHE MS‑1316‑C

• Configuration: 13 inputs (12 satellite IF + 1 terrestrial) → 16 subscriber outputs

📡 Key Specifications

Based on the product description (e.g., MS‑1312C/10x16 models), the MS‑1316‑C typically offers:

• Trunk Inputs: Quattro LNB inputs for four polarities per satellite × 3 satellites = 12 SAT inputs; plus 1 terrestrial.

• Frequency Range: ~47–2150 MHz (standard satellite + terrestrial)

• Built-in Amplification: Includes amplifier per output to ensure uniform signal levels

• Short-Circuit Protection: Present on all ports

• Isolation: High isolation between outputs and inputs to prevent signal interference

• Cascadable Design: Can be set up in cascade mode for larger distribution networks, or used standalone

✅ Typical Features (inherent to MS‑13xx‑C Series)

• Uniform Signal Quality: Equal output power across all 16 ports due to per-channel amplification

• Passive Terrestrial Path: Supports TV aerial signal injection

• LNB Switching and Indicator LEDs: For easy fault detection and control (as seen in MS‑1312C)
