SK1016

Quick Specs

• Inputs & Outputs: 4 satellite inputs + terrestrial input → 16 subscriber outputs

• Frequency Ranges:

  • Satellite: 950–2250 MHz

  • Terrestrial: 47–862 MHz

• Insertion Loss (Through‑pass Attenuation):

  • Terrestrial: +0 to +2 dB

  • Satellite: +3 dB ±2 dB

• Connection Gain:

  • Terrestrial: +1 dB ±2 dB

  • Satellite: +3 dB ±2 dB

• Decoupling:

  • Satellite ↔ Terrestrial: >25 dB

  • Satellite ↔ Satellite: >40 dB

  • H/V Band decoupling: >30 dB

  • Subscriber lines (isolation): >40 dB

• Output Level (Satellite): Up to ~102 dBμV (IMA‑3)

⚡ Power & Integration

• Power Options: Typically powered via coaxial cable, external injector, or dedicated PSU.

• Use Case: Designed for distributing satellite and terrestrial TV across 16 rooms or devices — ideal for medium-sized homes or small commercial setups.

• Compatibility: Works with standard Quattro LNBs; terrestrial antenna signal is combined and distributed alongside satellite feeds.

✅ Key Strengths

• Supports a large number of outputs while maintaining strong signal levels.

• Excellent cross‑coupling and subscriber isolation minimize interference and ensure signal integrity.

• Compact and efficient solution—a single unit for mixed radio and TV signal delivery.
