SK1048

Core Specs

• Inputs:

  • 8 satellite IF inputs (supports 4 dual‑output LNBs)

  • 1 terrestrial (VHF/UHF) input

  • 1 power/return‑path or global input — total 10 inputs

• Outputs:

  • 48 subscriber ports — perfect for high‑density installations

⚙️ Signal & Performance

• Frequency Range:

  • Satellite: 950–2150 MHz

  • Terrestrial: approx. 47–862 MHz

• Signal Handling:

  • Low insertion loss (~0–5 dB) to preserve signal strength

  • High isolation (≥ 30 dB) between satellite and terrestrial paths and across outputs

  • Output levels typically ~100 dBµV (satellite) and ~85 dBµV (terrestrial) for robust delivery

🔌 Power, Control & Installation

• Power Supply: Usually includes external DC Power Unit (18 V/2–3 A)

• Cascadable: Designed to work in cascade chains for even larger systems

• DiSEqC Compatibility: Automatically switches satellite inputs based on receiver commands (13/18 V + 22 kHz tone)

• Housing: Durable metal casing, rack‑ or wall‑mountable

✅ Use Cases

• Best suited for large commercial or residential systems—such as hotels, large apartment blocks, dormitories, or office buildings—serving up to 48 TVs or receivers.

• Efficiently aggregates multiple LNBs and terrestrial antenna feeds into a single distribution hub.
