SK1416

Core Specs

• Inputs:

  • Typically 4 satellite IF inputs (from a Quattro LNB or multiple LNB array)

  • 1 terrestrial (VHF/UHF) antenna input

• Outputs:

  • Up to 16 subscriber ports, ideal for multi-room setups

⚙️ Signal Capabilities

• Frequency Range:

  • Satellite: 950 – 2150 MHz

  • Terrestrial: 47 – 862 MHz

• Signal Gain/Loss:

  • Low insertion loss; built-in amplifiers boost both satellite and terrestrial signals

• Isolation & Decoupling:

  • High isolation between satellite inputs and outputs (typically > 30–35 dB), and between satellite and terrestrial paths (≥ 25 dB)

• Output Levels:

  • Satellite: ~100 dBµV (IMA-3 standard)

  • Terrestrial: ~85 dBµV

🔌 Power & Control Features

• Power Supply: Includes an external DC adapter (commonly 18 V/2–3 A), with cascaded design for larger installations

• Switching Control: Uses DiSEqC (13/18 V + 22 kHz) to dynamically route signals based on receiver commands

✅ Ideal Use Cases

• Designed for medium-sized residential or commercial settings—apartments, hotels, offices—serving up to 16 receivers

• Supports combined distribution of satellite and terrestrial TV signals over single cables to each outlet

• Compact metal housing suitable for indoor installation; multiple units can be cascaded for expanded coverage
