SK1432

Core Specifications

• Inputs & Outputs

  • Satellite: 12 IF inputs (from 3 Quattro LNBs), plus 1 terrestrial antenna input → 14 inputs

  • Subscriber Outputs: 32 configurable ports

• Frequency Coverage

  • Satellite IF: 950–2150 MHz

  • Terrestrial: 47–862 MHz

• Signal Quality & Performance

  • Built-in amplifier for enhanced signal levels

  • Low insertion loss, with high isolation:

    • Satellite ↔ Terrestrial: ≈25 dB

    • Between satellite polarities: ≈30–35 dB

    • Subscriber isolation: ≥ 30 dB

  • Satellite output up to ~100 dB µV compliant with IMA‑3/EN50083‑3 standards; terrestrial approx. 85 dB µV

• Switching & Control

  • Responds to standard DiSEqC commands (13 V/18 V, 22 kHz tone) to switch satellite inputs automatically

• Physical & Installation

  • Cascadable design (rack or wall mount compatible) with sturdy metal housing

  • Suitable for indoor use in residential or commercial installations

✅ Ideal Use Cases

Perfect for:

• Large apartment complexes, hotels, dormitories, or commercial buildings

• Systems requiring up to 32 satellite-equipped rooms with communal terrestrial signal

🔍 Why Choose the SK1432?

• High-capacity distribution (32 outputs from 14 inputs)

• Robust signal handling with integrated amplification and strong isolation

• Flexible DiSEqC switching, enabling full multisatellite setups

• Scalable and cascade-ready—great for growing installations
