SK1716

Core Features

• Inputs & Outputs:

  • 16 satellite IF inputs (4 satellite positions × 4 polarities/bands) + 1 terrestrial (VHF/UHF) input

  • Distributes combined signals to 16 subscriber outputs

• Frequency Performance:

  • Satellite: 950–2300 MHz

  • Terrestrial: 47–862 MHz (active) or 5–862 MHz (passive)

⚙️ Signal & Control

• Output Level: Satellite: up to 100 dBµV; Terrestrial (active): up to 95 dBµV

• Gain Settings:

  • Satellite tap gain: –5 dB (passive) or –1 dB (active)

  • Terrestrial gain: –2 dB (active); passive mode supports return path (5–65 MHz)

• DiSEqC Indication: Each output has an LED indicating proper receiver command execution

🔌 Power & Installation

• Power Supply:

  • Includes external PSU (13 V/4 A) for active configurations

  • In passive TV mode, power can be drawn from receivers via return channel

• Design: Compact “matrix switching”—connectors on both sides facilitate easy cabling

✅ Strengths & Applications

• Robust Signal Coverage: Up to 100 dBµV ensures strong signal delivery, even over long cable runs (tested up to 60 m with 6.7 mm coax)

• Full Return Path Support: Active/passive modes give flexible options, especially for interactive services

• Compact & Efficient: Built-in LEDs and DIP-switch selectable gain make installation and troubleshooting user-friendly

• Ideal For: Medium-sized SMATV or multi-dwelling installations—perfect for buildings needing reliable satellite + terrestrial TV across 16 rooms or devices.
